angr from First Principles: A picoCTF Tutorial for Beginners Tired of Magic

The first time I ran an angr script, I felt like a fraud

The first time I ran an angr script and it printed picoCTF{...}, I felt like a fraud. angr is a Python framework for binary analysis. I'd copy-pasted somebody's GitHub script that used it. I had no idea what claripy.BVS was. I had the vaguest sense of what symbolic execution(a program-analysis technique that explores many execution paths at once by treating inputs as symbolic variables) meant. And yet my terminal had the flag. If you've had that exact moment, this is the post that should have followed it.

People reach for angr on Capture-the-Flag (CTF) reverse-engineering challenges where the binary checks an input and you'd rather not unwind every branch by hand. The reputation it has, fairly, is that it works like a charm or it eats your RAM and dies. The reputation it deserves is more boring. angr is two pieces glued together: a CPU emulator that pretends to run the binary, and a constraint solver (a tool that takes a set of equations like x > 5 and x*x == 49 and returns a value of x that makes them all true). Once you can see those two layers separately, every "just use angr lol" script becomes a thing you can read, debug, and write.

The hard part isn't writing the four lines. It's knowing the binary well enough to fill in the four blanks correctly.

This post is for picoCTF beginners and anybody who's solved a few reverse challenges and is tired of feeling like they cheated. By the end you'll have a four-line skeleton, a debugging table for when the script returns nothing, and a five-question checklist for deciding if you should reach for angr in the first place. The challenges I anchor things to are classic-crackme-0x100 (picoCTF 2024), autorev-1 (picoCTF 2026), and virtual-machine-1 (picoCTF 2023). One where angr glows. One where it needs help. One where it dies.

Every angr script does the same four things

Open any angr writeup on the internet. The script will look elaborate. It probably has imports you've never seen, a comment about a hook, maybe a custom subclass. Strip all of that away and what's left is four moves, in the same order, every time.

import angr, claripy

# 1. Load the binary.
proj = angr.Project('./binary', auto_load_libs=False)

# 2. Plant a symbolic input.
INPUT_LEN = 32
password = claripy.BVS('password', 8 * INPUT_LEN)
state    = proj.factory.entry_state(stdin=password)

# 3. Choose how exploration ends.
simgr = proj.factory.simulation_manager(state)
simgr.explore(
    find  = lambda s: b'Correct' in s.posix.dumps(1),
    avoid = lambda s: b'Wrong'   in s.posix.dumps(1),
)

# 4. Ask the solver to finish the job.
if simgr.found:
    sol = simgr.found[0]
    print(sol.solver.eval(password, cast_to=bytes))

The reason this matters isn't aesthetic. It's diagnostic. When an angr script fails (and it will, often) the failure almost always traces back to exactly one of the four blanks being filled in wrong. We'll cash that claim in two sections.

The skeleton above is canonical. The official angr docs frame the same flow as "load a binary, define what input is symbolic, set the simulation manager loose, ask the solver for an assignment" (angr docs). The angr_ctf workshop, which is the closest thing this community has to a curriculum, walks you through 18 challenges that each modify exactly one of the four blanks. Lesson 00 is about the third blank (find). Lesson 01 adds avoid. Lessons 03 to 07 vary the second blank (registers, stack, memory, dynamic memory, files). Lessons 09 and 10 add hooks andSimProcedures, which are also tweaks to blank two. The whole curriculum is variations on the same skeleton. This is not me being clever. It's the architecture.

The mental model: a constraint solver wrapped around a CPU emulator

Here's the version that fits in your head. angr does two things, and when something breaks you can usually blame exactly one of them. The first thing is the emulator: it walks every instruction in the binary as if running it, but with your input held as a variable rather than a concrete value. The second is the solver: it watches the comparisons the emulator does and remembers them as equations, then answers the question "what input would have made this branch go the way I want?"

Why your script returned no states (a four-blank diagnostic)

The single most common angr-as-a-beginner experience is running the script, watching the output, and seeing this:

<SimulationManager with 0 found, 1 deadended>

Zero found. The simulation finished, no path reached your find. There's almost always a specific reason, and it's almost always one of the four blanks. Walk down the table, top to bottom, fixing each in turn.

The autorev-1 challenge is the textbook case for the second row. It accepts a fixed-length password and the angr solution falls out the moment you read the binary carefully enough to know what that length is. The receipt is in the writeup; the lesson is that the "script" problem was never a script problem. It was a binary-reading problem, and angr is paying you back for the time you spent in Ghidra.

Is this an angr challenge? Five questions

Before you start writing the script, ask the binary five questions. Three or more "yes" answers and angr is the right reach. Two or fewer and you're probably better off in Ghidra plus a Python solver, or just GDB (the GNU Debugger).

angr glows here: classic-crackme-0x100

The picoCTF 2024 classic-crackme-0x100 binary is a five-yes. It reads a fixed-length password. The check is a sequence of modulo-26 arithmetic transforms plus a final string compare. There's a clear "Correct!" string and a clear "Wrong" string. No network, no filesystem, no syscalls. Path count is small. This is what every angr tutorial uses as its hello-world for a reason.

The four blanks fill themselves in, but only after a couple of minutes in the binary. Here's the move that's easy to skip and shouldn't be: open crackme100 in Ghidra, click into main, and find the line that reads input. It's a scanf("%19s", buf). The %19s is your input length, full stop. The "Correct" and "Wrong" strings show up in the same view (or run strings ./crackme100 | grep -iE 'correct|wrong'). Now you have the four blanks. The script becomes mechanical.

import angr, claripy

proj = angr.Project('./crackme100', auto_load_libs=False)

# Read in Ghidra: scanf("%19s", buf), so 19 bytes plus null.
INPUT_LEN = 19
password = claripy.BVS('password', 8 * INPUT_LEN)
state = proj.factory.entry_state(
    stdin = angr.SimFile(content=password + b'\n'),
)
# Keep the bytes printable so the solver doesn't pick \x00.
for byte in password.chop(8):
    state.solver.add(byte >= 0x20, byte <= 0x7e)

simgr = proj.factory.simulation_manager(state)
simgr.explore(
    find  = lambda s: b'Correct' in s.posix.dumps(1),
    avoid = lambda s: b'Wrong'   in s.posix.dumps(1),
)

if simgr.found:
    sol = simgr.found[0]
    print(sol.solver.eval(password, cast_to=bytes))

Two notes. The auto_load_libs=False flag is doing real work: it tells angr not to load libc and the dynamic linker into the analysis. The default would load everything in ldd output (the Linux command that lists a binary's shared-library dependencies) and try to symbolically execute through it, which Subwire (an angr maintainer) describes plainly as "insanely painful." The built-in SimProcedure summaries for common libc calls are good enough for a crackme.

Second, the state.solver.add(byte >= 0x20, byte <= 0x7e) loop is the guard against the "solver returns nonsense bytes" row of the diagnostic. The binary technically accepts any byte at the symbolic positions; the printable constraint tells Z3 to give us a password we can actually type back into the program.

angr struggles here: the virtual-machine dispatch loop

Now the picoCTF 2023 virtual-machine-1 binary. It implements a custom bytecode virtual machine. There's a main loop that fetches an opcode byte, dispatches via a switch with a few dozen arms, and loops back. Your input feeds into one of those opcodes. Five-yes question one is yes, question two is yes, question five is yes. But question three (fewer than ~20 input-dependent branches) is screaming.

Two ways out, in order of how often I reach for them.

Hook the dispatch. If the VM's opcode handlers do something simple (load constant, XOR, compare), you can replace the dispatch with a Python SimProcedure that interprets the bytecode directly and updates state in one step instead of forking through the switch. The angr docs have a section on this; the rule of thumb is "if the function takes a function pointer or runs a hot loop, hook it."

Drop angr and write a small emulator in Python. Maintainable, debuggable, fast. The existing writeup on this site does exactly this: a dictionary mapping opcode bytes to handler functions, a register array, a program counter, a trace flag for diagnostics. For VM challenges I land on the emulator side maybe seven times out of ten. angr can do it, but the hooks you have to write to make it tractable end up being the same code as the emulator, minus the pleasant Python feedback loop.

The trick to using angr on a hard challenge isn't fighting it. It's knowing when not to bring it to the fight.

What angr won't do, and why that's good news

A short list of things angr will not do for you, no matter how much RAM you give it.

• Invert real cryptography. If the binary computes SHA-256 or AES on your input and compares the result to a constant, Z3 will not solve that in this millennium. Skip angr; the challenge wants a different shape (hash cracking, AES weaknesses).
• Read your mind about success conditions. If there's no ASCII string and no clear "flag printed here" address, you have to find one in Ghidra and pass it explicitly as a target address.
• Recover from missing system calls or unusual loaders. Static binaries, ARM firmware, kernel modules, anything that involves syscalls SimOS doesn't implement. The angr docs flag this as a known gotcha and the fix is always "hook it yourself."
• Reason about self-modifying code by default. It can, but you have to ask for it explicitly. Most beginners hit a wall here and assume angr is broken.

That list isn't a flaw. It's a feature. angr is a path-finder, not a reverser. The reason "just use angr lol" fails as advice is that it skips the whole step where you decide whether the binary is shaped like a path-finding problem at all. Which is the step the four-blank skeleton, the diagnostic, and the checklist are all trying to make explicit.

Next reverse challenge that fits the shape, you're going to know it before you open Ghidra. Open the binary, count the input bytes, find the "Wrong" string, write four lines, run it. That's the whole tutorial.

Quick reference

The skeleton, the diagnostic, the checklist, in one place.

# 1. Load
proj = angr.Project('./binary', auto_load_libs=False)

# 2. Symbolic input
x = claripy.BVS('x', 8 * INPUT_LEN)
state = proj.factory.entry_state(stdin=x)

# 3. End condition
simgr = proj.factory.simulation_manager(state)
simgr.explore(find=..., avoid=...)   # or simgr.run(); filter deadended

# 4. Finish with the solver
sol = simgr.found[0].solver.eval(x, cast_to=bytes)

• 0 found, fast finish: blank #3 wrong (find/avoid string not in binary).
• 0 found, slow finish: blank #2 wrong (input length).
• Many active, no progress: path explosion. Hook hot functions.
• Found, nonsense bytes: blank #4. Add printable-byte constraints.
• Crashes with UnsupportedSyscall: hook the syscall.

Related guides on this site:

• Ghidra for CTF (read the binary first; angr rewards it).
• GDB for CTF (when angr stalls, GDB at the comparison address is a faster answer).
• Frida (runtime instrumentation, the "hook a function" cousin).
• picoCTF beginner's guide.

External primary sources:

• angr docs: Symbolic Execution
• angr docs: Gotchas
• angr docs: SimProcedures and Hooks
• jakespringer/angr_ctf workshop
• Shoshitaishvili et al., (State of) The Art of War, IEEE S&P 2016
• Springer, Teaching with angr, USENIX ASE 2018
• Gustafson, Throwing a Tantrum (angr internals)
