Wireshark and pcap Analysis for CTF Forensics

Introduction

Network forensics challenges give you a packet capture file (usually a .pcap or .pcapng file) recorded from a real or simulated network. Your job is to find the flag hidden somewhere inside the traffic: in a plaintext HTTP response, embedded in a file transferred over FTP, encoded in DNS queries, or smuggled inside a protocol you wouldn't normally suspect.

Wireshark is the standard tool for this work. It parses and dissects hundreds of protocols, lets you reconstruct TCP streams as readable text, and can export files from network transfers. This guide covers the skills needed for challenges like Packets Primer, Eavesdrop, Wireshark doo dooo do doo, Wireshark twoo twooo two twoo, pcap poisoning, and shark on wire 1.

Opening a pcap file

Install Wireshark on Ubuntu or Debian:

sudo apt install wireshark

Open a capture file from the command line or via File → Open:

wireshark challenge.pcap

Wireshark also accepts compressed files (.pcap.gz) and the newer .pcapng format that supports multiple interfaces and packet comments.

The Wireshark interface

The Wireshark window has three main panes:

• Packet list (top): one row per packet, showing number, timestamp, source, destination, protocol, and a summary.
• Packet details (middle): the dissected protocol tree for the selected packet. Click any row to expand it.
• Packet bytes (bottom): the raw hex and ASCII representation. Selecting a field in the details pane highlights the corresponding bytes here.

The display filter bar at the top is where you type filters to hide irrelevant packets. Press Enter or the arrow button to apply. The bar turns red for an invalid filter and green for a valid one.

Following TCP/UDP streams

Reconstructing a complete conversation from individual packets is the most useful forensics operation. Right-click any packet in a TCP flow and choose Follow → TCP Stream. Wireshark reassembles all the packets in that flow into a single readable window, with client data in red and server data in blue.

This instantly shows you the full HTTP request and response, an FTP data transfer, or a shell session. Many CTF flags are directly visible as plaintext in a stream view.

At the bottom of the stream window you can switch the display to:

• ASCII: printable characters (default)
• Hex Dump: raw bytes alongside ASCII
• Raw: the raw byte stream, useful for saving binary data

For UDP flows, use Follow → UDP Stream. For DNS challenges use Statistics → DNS or filter on dns and examine individual query names in the packet detail tree.

Display filters

Display filters narrow the packet list to only the packets you care about. Wireshark uses its own filter language (not Berkeley Packet Filter). Some essential filters:

Finding credentials

Plaintext protocols like HTTP (not HTTPS), FTP, Telnet, and POP3 transmit usernames and passwords in the clear. Wireshark can extract them automatically:

Go to Tools → Credentials. Wireshark scans the capture for known credential patterns across dozens of protocols and lists them in a separate window with the packet number, protocol, username, and password.

For HTTP Basic Auth, filter to http.authbasic and read the Authorization header. The value is Base64-encoded; decode it to recover username:password.

# Decode HTTP Basic Auth from the terminal
echo 'dXNlcjpwYXNz' | base64 -d
# user:pass

Extracting files from captures

Files transferred over HTTP, FTP, SMB, or TFTP are reconstructed by Wireshark automatically. Go to File → Export Objects and choose the protocol. Wireshark lists every transferred file with its filename and size. Save the ones you want to disk.

For protocols not in the Export Objects menu, follow the TCP stream, switch the view to Raw, then click Save As to write the raw bytes to a file.

tshark on the command line

tshark is the command-line version of Wireshark. It is invaluable when you want to grep, pipe, or script analysis of a large capture without a GUI.

# List all HTTP requests
tshark -r capture.pcap -Y 'http.request' -T fields \
  -e ip.src -e http.request.method -e http.request.uri
# Print every DNS query name
tshark -r capture.pcap -Y 'dns.qry.name' -T fields -e dns.qry.name
# Follow TCP stream 0 and print as ASCII
tshark -r capture.pcap -q -z follow,tcp,ascii,0
# Extract all HTTP objects to a folder
tshark -r capture.pcap --export-objects http,/tmp/exported_files
# Search for the flag in any packet payload
strings capture.pcap | grep 'picoCTF'

TLS and encrypted traffic

HTTPS traffic is encrypted, so you cannot read the payload directly. However, TLS connections still expose useful metadata in the handshake, and some CTF setups give you a key log file to decrypt everything.

Extracting metadata without decryption

The TLS ClientHello packet is sent in the clear and contains the Server Name Indication (SNI), which reveals which hostname the client was connecting to. This is often enough to identify the suspicious connection in a capture.

# Extract all SNI values (server names) from TLS handshakes:
tshark -r cap.pcap -Y 'tls.handshake.type == 1' \
  -T fields -e tls.handshake.extensions_server_name
# Extract certificate Common Names from the capture:
tshark -r cap.pcap -Y 'x509sat.printableString' \
  -T fields -e x509sat.printableString | sort -u
# Wireshark filter to isolate TLS traffic to a specific domain:
tls.handshake.extensions_server_name == "suspicious.attacker.com"

Decrypting TLS with a key log file

Some challenges provide a SSLKEYLOGFILE (a file containing TLS session keys logged by the browser or client). If you have one, Wireshark can decrypt the entire TLS session:

# In Wireshark:
Edit -> Preferences -> Protocols -> TLS
  -> (Pre)-Master-Secret log filename: browse to the .log file
# Wireshark will now show decrypted HTTP/2 or HTTP traffic inside the TLS streams.
# With tshark:
tshark -r cap.pcap -o 'tls.keylog_file:/path/to/sslkeys.log' \
  -Y 'http' -T fields -e http.request.uri -e http.file_data

ICMP covert channels

ICMP (ping) packets should have a small, fixed payload. When you see ICMP packets with unusually large or non-standard payloads, the data may be a covert channel carrying the flag.

# Filter to ICMP packets with data payloads:
icmp
# With tshark, extract each ICMP payload as hex:
tshark -r cap.pcap -Y icmp -T fields -e data.data
# Concatenate and decode:
tshark -r cap.pcap -Y icmp -T fields -e data.data | tr -d '\n' | xxd -r -p

Common CTF patterns

Flag in HTTP response body

The most common beginner pattern. Filter to http, follow the stream of a suspicious request, and read the response. The flag may be in the HTML body, a JSON field, or a custom header. Used in Packets Primer and Wireshark doo dooo do doo.

Flag in DNS exfiltration

Flags are sometimes encoded as subdomain labels in DNS queries, e.g. cGljb0NURg.attacker.com. The data is split across multiple queries, each carrying one chunk as a subdomain label. To reconstruct:

# 1. Extract all unique query names:
tshark -r cap.pcap -Y dns.qry.name -T fields -e dns.qry.name | sort -u
# 2. Strip the common parent domain and sort by order (often a sequence number prefix):
# Example queries: 01-cGljb0N.exfil.com  02-RGSB5Y3Q.exfil.com  03-dGZ7ZG5z.exfil.com
# 3. In Python: extract, join, and decode:
import base64
chunks = ['cGljb0N', 'RGSB5Y3Q', 'dGZ7ZG5z']  # extracted labels in order
combined = ''.join(chunks)
# Fix base64 padding:
combined += '=' * (4 - len(combined) % 4)
print(base64.b64decode(combined))

Exfiltration channels frequently stack base32 or hex inside a base64 outer layer. Paste the concatenated result into Recipe Chain and run Magic to peel apart nested encodings automatically. Used in Wireshark twoo twooo two twoo.

Credentials used as the flag

Some challenges are solved by finding a username or password that is itself the flag, or leads to a service where the flag lives. Use Tools → Credentials or filter to the relevant plaintext protocol. Used in Eavesdrop.

Modified or injected packets

In pcap poisoning, extra packets have been injected into a legitimate capture. Look for packets that break the normal conversation flow (out-of-sequence TCP, responses with no matching request, packets from unexpected source IPs) and inspect their payloads directly.

Unusual protocol

Check Statistics → Protocol Hierarchy. If you see an unexpected protocol like ICMP with large payloads, raw TCP on a non-standard port, or an unrecognized stream, that is usually the carrier for the hidden data. Used in shark on wire 1 and shark on wire 2.

Quick reference

Practice with: Packets Primer, Eavesdrop, Wireshark doo dooo do doo, Wireshark twoo twooo two twoo, pcap poisoning, shark on wire 1.
